TBL-SERIES BI-DIRECTION FLAT & BEND GLASS TEMPERING FURNACE (RIGID SHAFT BENDING)
Video link,
https://youtu.be/xvmvLAp-g4c
| Model | Max. Loading Area | Min.Glass Size | Thickness | Min.Radius |
| (mm) | (mm) | (mm) | (mm) |
| LV-TB1206L | 1200 x ⌒600 | 150 x 280 | 3～19 | ≧350 |
| LV-TB1608L | 1200 x ⌒800 | 150 x 280 | 4～19 | ≧450 |
| LV-TB2010L | 2010 x ⌒1000 | 150 x 280 | 4～19 | ≧500 |
| LV-TB2412L | 2440 x ⌒1200 | 150 x 280 | 4～19 | ≧550 |
| LV-TB2415L | 2440 x ⌒1500 | 150 x 320 | 5～19 | ≧700 |
| LV-TB3025L | 3000 x ⌒2500 | 150 x 320 | 5～19 | ≧1200 |
Bend glass Application (or customerized) :
For producing the bent tempered glass for side windows of car,
shower room, capsule elevator, facades of small architecture
(arc-shaped balcony), etc.
Popular bending glass size (as max. bent glass size)
⌒600mm | ⌒1000mm | ⌒1500mm | ⌒2000mm |
⌒800mm | ⌒1200mm | ⌒1600mm | ⌒2500mm |
The straight side length could be: 1220mm; 1500mm; 1700mm; 1800mm;
2000mm; 2440mm; 3000mm |
1. This machine is used to produce the flat & bent tempered glass.
The processed glass can be used for buildings, shower room,
sidelite of car or bus, etc.
2.The machine adopts industrial control computer and PLC, the speed
can be adjusted by the inverter steplessly. High automation made it
reliable and precise, easy to operate and efficiency.
3.Conveying speed of the glass entering and exiting the heating
oven is controlled by inverter, which can assure high
synchronization and avoid scratch on the glass.
4.Heating section has a helix matrix structure, which can control
the temperature independently. Reasonable design and unique
structure of heating elements make a long serve life.
5. The heating oven body is full closed and the Insulating
materials are of high quality material with top performance which
can ensure a lower energy consumption.
6. The emergency cooling system is greatly convenient for machine
maintenance.
7. The proportion of the air pressure between the upper quench and
the lower quench can be adjusted.
8. The operaton for bending forming is easy and the forming
precision is very high, also, it is very easy to change the glass
type during production.
9. The software has a powerful function, which is very convenient
for operation, maintenance and adjustment.
10. The whole production procedure is controlled and monitored by
computer, which is of high automation.
